Дома / ///ASUS TUF GAMING B550-PLUS WIFI II AMD B550 Socket AM4 ATX
Новый ASUS TUF GAMING B550-PLUS WIFI II AMD B550 Socket AM4 ATX

ASUS TUF GAMING B550-PLUS WIFI II AMD B550 Socket AM4 ATX

ASUS

90MB19U0-M0EAY0

Новый продукт

41 Элементы

Shipping 2025-11-14 days

149,00 € включая налог.

BIOS
BIOS typeUEFI AMI
Expansion slots
Number of M.2 (M) slots2
PCI Express x1 (Gen 3.x) slots3
PCI Express x16 (Gen 3.x) slots1
PCI Express x16 (Gen 4.x) slots1
Features
Audio output channels7.1 channels
Motherboard chipsetAMD B550
Motherboard chipset familyAMD
Motherboard form factorATX
Product colourBlack
Windows operating systems supportedWindows 10
Windows operating systems supportedWindows 11
Graphics
Number of displays supported2
On-board graphics cardNo
Parallel processing technology supportNot supported
Internal I/O
ATX Power connector (24-pin)Yes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Number of chassis fan connectors3
Number of COM connectors1
Number of SATA III connectors6
RGB LED pin headerYes
Thunderbolt headers1
TPM connectorYes
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Logistics data
Harmonized System (HS) code84733020
Memory
ECC сompatibilityECC
Maximum internal memory128 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory clock speeds3200
Supported memory clock speeds2666
Supported memory clock speeds4266
Supported memory clock speeds3400
Supported memory clock speeds3866
Supported memory clock speeds3733
Supported memory clock speeds4400
Supported memory clock speeds4133
Supported memory clock speeds4000
Supported memory clock speeds4800
Supported memory clock speeds4866
Supported memory clock speeds3333
Supported memory clock speeds4466
Supported memory clock speeds2133
Supported memory clock speeds4200
Supported memory clock speeds3000
Supported memory clock speeds2933
Supported memory clock speeds3600
Supported memory clock speeds2400
Supported memory clock speeds2800
Supported memory clock speeds3466
Supported memory clock speeds4333
Supported memory clock speeds4600
Supported memory typesDDR4-SDRAM
Unbuffered memoryYes
Network
BluetoothYes
Bluetooth version5.2
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Wi-FiYes
Wi-Fi standards802.11g
Wi-Fi standards802.11a
Wi-Fi standardsWi-Fi 6 (802.11ax)
Wi-Fi standards802.11b
Wi-Fi standardsWi-Fi 4 (802.11n)
Wi-Fi standardsWi-Fi 5 (802.11ac)
Other features
Packaging content2 x SATA 6Gb/s cables 1 x ASUS Wi-Fi moving antennas 1 x I/O Shield 1 x M.2 Rubber package 1 x M.2 SSD screw package 1 x TUF Gaming sticker 1 x Support DVD 1 x TUF Certification card 1 x User guide
Weight945 g
Packaging content
Cables includedSATA
Drivers includedYes
Processor
Compatible processor seriesAMD Ryzen 3000 Series
Processor manufacturerAMD
Processor socketSocket AM4
Supported processor socketsSocket AM4
Rear panel I/O ports
DisplayPorts quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
Headphone outputs1
Line-inYes
Microphone inYes
S/PDIF out portYes
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB connector typeUSB Type-A
USB connector typeUSB Type-C
Safety warning
WarningsDispose of according to local electro-waste regulations.
WarningsStore away from water and sources of moisture.
WarningsAvoid direct contact with sensitive electronic components.
Storage controllers
RAID levels1
RAID levels10
RAID supportYes
Supported storage drive interfacesM.2, SATA
Supported storage drive typesHDD & SSD
Weight & dimensions
Depth244 mm
Height75 mm
Width305 mm
