Дома / ///DeepCool PF500 power supply unit 500 W 20+4 pin ATX ATX Black
Новый DeepCool PF500 power supply unit 500 W 20+4 pin ATX ATX Black

DeepCool PF500 power supply unit 500 W 20+4 pin ATX ATX Black

DEEPCOOL

R-PF500D-HA0B-EU

Новый продукт

110 Элементы

Shipping 2025-11-14 days

39,00 € включая налог.

Design
Cooling typeActive
Fan diameter12 cm
Number of fans1 fan(s)
On/off switchYes
Product colourBlack
Operational conditions
Operating temperature (T-T)0 - 40 °C
Packaging content
Cables includedAC
Packaging data
Package typeBox
Performance
80 PLUS certification80 PLUS
ATX version2.4
Mean time between failures (MTBF)100000 h
Power supply unit (PSU) form factorATX
PurposePC/Server
Ports & interfaces
Cabling typeNon-Modular
EPS power connector (4+4 pin)Yes
Motherboard power cable length55 cm
Motherboard power connector20+4 pin ATX
Number of SATA power connectors4
PCI Express power connectors (6+2 pin)2
SATA power cable length900 mm
SATA power cable length750 mm
SATA power cable length600 mm
SATA power cable length450 mm
Power
AC input frequency50 Hz
AC input voltage220 - 240 V
Combined power (-12V)3.6 W
Combined power (+12V)480 W
Combined power (+3.3V)100 W
Combined power (+5V)100 W
Combined power (+5Vsb)12.5 W
Efficiency85%
Hold time16 ms
Max output current (-12V)0.3 A
Max output current (+12V)40 A
Max output current (+3.3V)15 A
Max output current (+5V)15 A
Max output current (+5Vsb)2.5 A
Power protection featuresUnder voltage
Power protection featuresOver power
Power protection featuresShort circuit
Power protection featuresOver voltage
Total power500 W
Weight & dimensions
Depth140 mm
Height86 mm
Width150 mm
