Home / ///TP-Link Omada ES208G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black
New TP-Link Omada ES208G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black

TP-Link Omada ES208G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black

TP-LINK

ES208G

New product

49 Items

Shipping 2025-11-14 days

39,00 € tax incl.

Certificates
Compliance certificatesRoHS
Compliance certificatesCE
Compliance certificatesFederal Communications Commission (FCC)
Data transmission
Forwarding rate11.9 Mpps
Jumbo frames15000
Jumbo frames supportYes
MAC address table8000 entries
Packet buffer memory4 MB
Store-and-forwardYes
Switching capacity16 Gbit/s
Design
LED indicatorsYes
Product colourBlack
Rack mountingNo
StackableNo
Wall mountableYes
Management features
Cloud-managedYes
Quality of Service (QoS) supportYes
Switch layerL2
Switch typeManaged
Unified static configurationYes
Web-based managementYes
Network
10G supportNo
Auto MDI/MDI-XYes
Auto-negotiationYes
Fast leaveYes
Flow control supportYes
Link aggregationYes
Networking standardsIEEE 802.1Q
Networking standardsIEEE 802.3x
Networking standardsIEEE 802.3ab
Networking standardsIEEE 802.1p
Networking standardsIEEE 802.3i
Networking standardsIEEE 802.1ab
Networking standardsIEEE 802.3at
Number of VLANs32
Port mirroringYes
Virtual LAN featuresTagged VLAN
Virtual LAN featuresPort-based VLAN
Virtual LAN featuresMTU VLAN
VLAN supportYes
Zero Touch Provisioning (ZTP)Yes
Operational conditions
Heat dissipation9.09 BTU/h
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-5 - 45 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C
Packaging content
User guideYes
Packaging data
AC adapter includedYes
Package typeBox
Performance
FanlessYes
Firmware upgradeableYes
Flash memory64 MB
Mean time between failures (MTBF)1141726 h
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity8
Power
DC input voltage5 V
Input current0.6 A
Power consumption (max)2.7 W
Power sourceDC
Power supply includedYes
Surge protectionYes
Surge protection voltage6 kV
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Security
DHCP featuresDHCP client
IGMP snoopingYes
Loop protectionYes
Queue scheduling algorithmsWeighted Round Robin (WRR)
Weight & dimensions
Depth100.7 mm
Height25.4 mm
Width158 mm
