New TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch

TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch

TP-LINK

TL-SG1024D

New product

74 Items

Shipping 2025-11-17 days

99,00 € tax incl.

Data transmission
Forwarding rate35.7 Mpps
Jumbo frames10000
Jumbo frames supportYes
MAC address table8000 entries
Maximum data transfer rate1 Gbit/s
Store-and-forwardYes
Supported data transfer rates10/100/100 Mbps
Switching capacity48 Gbit/s
Design
CertificationFCC, CE, RoHS
LED indicatorsYes
Product colourGrey
Rack mountingYes
StackableYes
Logistics data
Harmonized System (HS) code85176990
Management features
Quality of Service (QoS) supportYes
Switch typeUnmanaged
Network
10G supportNo
Auto MDI/MDI-XYes
Auto-negotiationYes
Cable types supportedCat4
Cable types supportedCat5
Cable types supportedCat5e
Cable types supportedCat3
Flow control supportYes
Full duplexYes
Networking standardsIEEE 802.3ab
Networking standardsIEEE 802.3u
Networking standardsIEEE 802.3x
Operational conditions
Heat dissipation46.44 BTU/h
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)32 - 104 °F
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C
Other features
Bandwidth48 Gbit/s
Connectivity LEDsY
Connectivity technologyWired
Dimensions (WxDxH)294 x 180 x 44 mm
Networking featuresGigabit Ethernet
Power requirements100 - 240V, 50/60Hz
Packaging data
Cables includedAC
Package depth400 mm
Package height80 mm
Package typeBox
Package weight1.95 kg
Package width250 mm
Rack mount kitYes
User guideYes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity24
Power connectorDC-in jack
Power
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Power consumption (max)13.62 W
Power sourceAC
Power supply includedYes
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Protocols
Supported network protocolsCSMA/CD, TCP/IP
Weight & dimensions
Depth180 mm
Height44 mm
Width294 mm
