| Certificates | |
| Certification | FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB, RoHS |
| Data transmission | |
| Jumbo frames support | Yes |
| MAC address table | 8000 entries |
| Maximum data transfer rate | 1 Gbit/s |
| Packet buffer memory | 0.128 MB |
| Store-and-forward | Yes |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 16 Gbit/s |
| Design | |
| Housing material | Metal |
| LED indicators | Link |
| LED indicators | Power |
| Product colour | Black |
| Rack mounting | No |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Management features | |
| Quality of Service (QoS) support | Yes |
| Network | |
| 10G support | Yes |
| Auto MDI/MDI-X | Yes |
| Copper ethernet cabling technology | 10BASE-T |
| Copper ethernet cabling technology | 100BASE-TX |
| Copper ethernet cabling technology | 1000BASE-T |
| Flow control support | Yes |
| Full duplex | Yes |
| Networking standards | IEEE 802.3 |
| Networking standards | IEEE 802.3ab |
| Networking standards | IEEE 802.1p |
| Networking standards | IEEE 802.3az |
| Networking standards | IEEE 802.3x |
| Networking standards | IEEE 802.3u |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -10 - 70 °C |
| Other features | |
| Connectivity technology | Wired |
| Data transfer rate | 2000 Mbit/s |
| Dimensions (WxDxH) | 162 x 102 x 28 mm |
| Packaging data | |
| Included power plug types | EU |
| Package depth | 250 mm |
| Package height | 68 mm |
| Package weight | 654 g |
| Package width | 208 mm |
| Performance | |
| Mean time between failures (MTBF) | 2053751 h |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Power connector | DC-in jack |
| Power | |
| Input current | 1 A |
| Input voltage | 5 V |
| Power consumption (typical) | 2.8 W |
| Safety warning | |
| Warnings | Do not open the case or try to repair it yourself. |
| Warnings | Ensure the unit is adequately ventilated during operation. |
| Warnings | The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. |
| Security | |
| MAC address filtering | Yes |
| Technical details | |
| Master (outer) cases per pallet (air) | 48 pc(s) |
| Master (outer) cases per pallet (sea) | 48 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 398.9 kg |
| Pallet gross weight (sea) | 398.9 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 196.7 cm |
| Pallet height (sea) | 196.7 cm |
| Products per pallet (air) | 480 pc(s) |
| Products per pallet (sea) | 480 pc(s) |
| Products per shipping (inner) case | 10 pc(s) |
| Shipping (inner) case gross weight | 7.79 kg |
| Shipping (inner) case height | 44.3 cm |
| Shipping (inner) case length | 37 cm |
| Shipping (inner) case net weight | 7.1 kg |
| Shipping (inner) case width | 26 cm |
| Weight & dimensions | |
| Weight | 440 g |
