Home / ///XPG COREREACTOR II 850W Power Supply
New XPG COREREACTOR II 850W Power Supply

XPG COREREACTOR II 850W Power Supply

XPG

75261197

New product

200 Items

Shipping 2025-11-14 days

119,00 € tax incl.

Certificates
CertificationCE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM
Design
Cooling typeActive
Fan diameter12 cm
Number of fans1 fan(s)
Product colourBlack
Packaging data
Package weight3.1 kg
Performance
80 PLUS certification80 PLUS Gold
ATX version3.0
Bearing technologyFDB
EPS version2.92
Mean time between failures (MTBF)100000 h
Power supply unit (PSU) form factorATX
PurposePC
Ports & interfaces
ATX power connector (12+4 pin)Yes
ATX Power connector (24-pin)Yes
Cabling typeFully-Modular
EPS power connector (8-pin)Yes
Motherboard power connector20+4 pin ATX
Number of SATA power connectors8
PCI Express power connectors (6+2 pin)6
Peripheral (Molex) power connectors (4-pin)4
Power
AC input frequency47 - 63 Hz
AC input voltage100 - 240 V
Input current12 A
Max output current (-12V)0.3 A
Max output current (+12V)62.5 A
Max output current (+3.3V)22 A
Max output current (+5V)22 A
Max output current (+5Vsb)3 A
Power factor0.99
Power protection featuresUnder voltage
Power protection featuresOver current
Power protection featuresShort circuit
Power protection featuresOver voltage
Power protection featuresOver power
Power protection featuresSurge & inrush protection (SIP)
Total power850 W
Safety warning
WarningsThe product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
WarningsDo not open the case - risk of electric shock.
WarningsAvoid contact of the product with water or other liquids.
Weight & dimensions
Depth150 mm
Height86 mm
Weight1.6 kg
Width140 mm
