| Data transmission | |
| Jumbo frames | 9216 |
| Jumbo frames support | Yes |
| MAC address table | 8000 entries |
| Number of queues | 8 |
| Number of static routes | 32 |
| Packet buffer memory | 0.512 MB |
| Store-and-forward | Yes |
| Switching capacity | 52 Gbit/s |
| Design | |
| Certification | CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC |
| LED indicators | Link |
| LED indicators | Activity |
| LED indicators | Speed |
| Number of fans | 3 fan(s) |
| Product colour | Blue |
| Rack mounting | Yes |
| Stackable | Yes |
| Management features | |
| Quality of Service (QoS) support | Yes |
| Switch layer | L2/L3/L4 |
| Switch type | Managed |
| System event log | Yes |
| Web-based management | Yes |
| Multicast features | |
| Multicast support | Yes |
| Number of multicast groups filtered | 128 |
| Network | |
| 10G support | Yes |
| Broadcast storm control | Yes |
| Copper ethernet cabling technology | 10BASE-T |
| Copper ethernet cabling technology | 100BASE-T |
| Copper ethernet cabling technology | 100BASE-TX |
| Copper ethernet cabling technology | 1000BASE-T |
| Flow control support | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Link aggregation | Yes |
| Networking standards | IEEE 802.1w |
| Networking standards | IEEE 802.3x |
| Networking standards | IEEE 802.1p |
| Networking standards | IEEE 802.1ab |
| Networking standards | IEEE 802.1as |
| Networking standards | IEEE 802.1D |
| Networking standards | IEEE 802.3z |
| Networking standards | IEEE 802.3ae |
| Networking standards | IEEE 802.3ad |
| Networking standards | IEEE 802.1s |
| Number of VLANs | 64 |
| Port mirroring | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Operational conditions | |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
| Optical fiber | |
| Fiber ethernet cabling technology | 1000BASE‑LX |
| Fiber ethernet cabling technology | 1000BASE‑SX |
| Packaging data | |
| Cables included | AC |
| Manual | Yes |
| Quick start guide | Yes |
| User guide | Yes |
| Performance | |
| Firmware upgradeable | Yes |
| Mean time between failures (MTBF) | 634966 h |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
| SFP module slots quantity | 2 |
| Power | |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 446.7 W |
| Power supply included | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 380 W |
| Protocols | |
| Management protocols | SNMP v1/v2/v3 |
| Security | |
| Access Control List (ACL) | Yes |
| DHCP features | DHCP client |
| IGMP snooping | Yes |
| MAC address filtering | Yes |
| Security algorithms | HTTPS |
| Security algorithms | 802.1x RADIUS |
| Security algorithms | SSL/TLS |
| SSH/SSL support | Yes |
| Weight & dimensions | |
| Depth | 204 mm |
| Height | 43 mm |
| Weight | 3.7 kg |
| Width | 440 mm |
