| Display | |
| Built-in display | No |
| Features | |
| Product colour | Black |
| Rack mounting | Yes |
| Hard drive | |
| HDD interface | SATA |
| Maximum storage capacity | 16 TB |
| RAID levels | 5 |
| RAID levels | 10 |
| RAID levels | 6 |
| RAID levels | 1 |
| RAID support | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 93% |
| Operating temperature (T-T) | -10 - 55 °C |
| Performance | |
| Alarm input channels | 16 |
| Alarm output channels | 8 |
| Audio formats supported | G.726 |
| Audio formats supported | PCM |
| Audio formats supported | G.711 |
| Backup function | Yes |
| Number of simultaneously playbacked channels | 16 channels |
| Supported resolutions | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1 |
| Video formats supported | H.264+ |
| Video formats supported | H.265 |
| Video formats supported | H.265+ |
| Video formats supported | MPEG4 |
| Video formats supported | H.264 |
| Video formats supported | M-JPEG |
| Video input channels | 64 channels |
| Ports & interfaces | |
| BNC audio input | Yes |
| BNC audio output | Yes |
| eSATA | Yes |
| eSATA ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI output | Yes |
| HDMI ports quantity | 4 |
| RS-232 ports | 1 |
| RS-485 ports | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) output ports | 2 |
| Power | |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power | 18 W |
| System requirements | |
| Browser supported | Chrome, IE 9 or later, Firefox |
| Mobile operating systems supported | Android |
| Mobile operating systems supported | iOS |
| Weight & dimensions | |
| Depth | 456.6 mm |
| Height | 95 mm |
| Package depth | 570 mm |
| Package height | 226 mm |
| Package weight | 10.3 kg |
| Package width | 570 mm |
| Weight | 6.4 kg |
| Width | 444 mm |
| Wireless LAN features | |
| Wi-Fi | Yes |
