Новый ASUS PRO WS W880-ACE SE Intel W880 LGA 1851 (Socket V1) ATX

ASUS PRO WS W880-ACE SE Intel W880 LGA 1851 (Socket V1) ATX

ASUS

90MB1KV0-M0EAY0

Новый продукт

6 Элементы

Shipping 2025-11-14 days

609,00 € включая налог.

BIOS
BIOS memory size256 Mbit
BIOS typeUEFI AMI
Clear CMOS buttonYes
Expansion slots
1st M.2 highest PCI Express generation5.0
1st M.2 largest key size2280
2nd M.2 highest PCI Express generation4.0
2nd M.2 largest key size2280
3rd M.2 highest PCI Express generation4.0
3rd M.2 largest key size2280
4th M.2 highest PCI Express generation4.0
4th M.2 largest key size2280
Number of M.2 (M) slots4
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 5.x) slots2
Features
Audio chipRealtek ALC1220P
Audio output channels7.1 channels
Component forWorkstation
Cooling typePassive
Motherboard chipsetIntel W880
Motherboard chipset familyIntel
Motherboard form factorATX
Power source typeATX
Product colourGrey
Windows operating systems supportedWindows 11
Windows operating systems supportedWindows 10 x64
Graphics
Maximum resolution3840 x 2160 pixels
Parallel processing technology supportNot supported
Internal I/O
12V power connectorYes
ATX Power connector (24-pin)Yes
Chassis intrusion connectorYes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Front panel connectorYes
Integrated SAS ports1
Number of chassis fan connectors5
Number of COM connectors1
Number of CPU fan connectors1
Number of EPS power connectors (8-pin)2
Number of SATA III connectors4
Number of temperature sensor headers1
Number of water pump connectors1
Thunderbolt headers1
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
Memory
ECC сompatibilityNon-ECC
Maximum internal memory256 GB
Maximum internal memory per slot64 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory clock speed (max)9066 MHz
Supported memory typesDDR5-SDRAM
Unbuffered memoryYes
Network
Ethernet interface typeGigabit Ethernet
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
Wi-FiNo
Packaging content
Cables includedSATA
Processor
Compatible processor seriesIntel Core Ultra (Series 2)
Processor manufacturerIntel
Processor socketLGA 1851 (Socket V1)
Supported processor socketsIntel LGA1851
Rear panel I/O ports
DisplayPort version2.1
Ethernet LAN (RJ-45) ports3
HDMI ports quantity1
HDMI version2.1
Headphone outputs1
Line-inYes
Thunderbolt ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
VGA (D-Sub) ports quantity1
Storage controllers
Number of HDDs supported4
Number of storage drives supported8
RAID levels5
RAID levels1
RAID levels10
RAID supportYes
Supported storage drive interfacesM.2, PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive typesHDD & SSD
Weight & dimensions
Depth244 mm
Width305 mm
