Дома / ///Материнская плата GIGABYTE H610M K DDR4 - поддержка процессоров Intel Core 14-го поколения, гибридный конструктив с 3+1+1 фазами
Новый Материнская плата GIGABYTE H610M K DDR4 - поддержка процессоров Intel Core 14-го поколения, гибридный конструктив с 3+1+1 фазами

Материнская плата GIGABYTE H610M K DDR4 - поддержка процессоров Intel Core 14-го поколения, гибридный конструктив с 3+1+1 фазами

Gigabyte

H610MKDDR4

Новый продукт

54 Элементы

Shipping 2025-11-24 days

79,00 € включая налог.

Battery
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Battery typeCR2032
Battery weight3 g
Lithium weight per battery0.07 g
Number of battery cells1
BIOS
ACPI version5.0
BIOS memory size128 Mbit
BIOS typeUEFI AMI
Clear CMOS buttonYes
Clear CMOS jumperYes
Desktop Management Interface (DMI) version2.7
System Management BIOS (SMBIOS) version2.7
Expansion slots
Number of M.2 (M) slots1
PCI Express x1 (Gen 3.x) slots1
PCI Express x16 (Gen 4.x) slots1
Features
Audio chipRealtek ALC897
Audio output channels7.1 channels
Component forPC
Motherboard chipsetIntel H610 Express
Motherboard chipset familyIntel
Motherboard form factormicro ATX
PC health monitoringTemperature
PC health monitoringWater cooling
PC health monitoringFan
PC health monitoringVoltage
Power source typeATX
Product colourBronze
Windows operating systems supportedWindows 11 x64
Windows operating systems supportedWindows 10 x64
Graphics
HDCPYes
Maximum resolution4096 x 2160 pixels
Parallel processing technology supportNot supported
Internal I/O
12V power connectorYes
ATX Power connector (24-pin)Yes
Audio connectorYes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Front panel connectorYes
Number of chassis fan connectors1
Number of EATX power connectors1
Number of SATA III connectors2
Power fan connectorYes
Total number of SATA connectors2
TPM connectorYes
USB 2.0 connectors1
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Logistics data
Country of originChina
Products per shipping (inner) case1 pc(s)
Memory
ECC сompatibilityECC & Non-ECC
Maximum internal memory64 GB
Maximum RDIMM memory64 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory clock speed (max)3200 MHz
Supported memory clock speeds3200 MHz
Supported memory clock speeds2666
Supported memory clock speeds2933
Supported memory clock speeds3000
Supported memory clock speeds2133
Supported memory clock speeds2400
Supported memory module capacities8GB
Supported memory module capacities32GB
Supported memory module capacities16GB
Supported memory module capacities2GB
Supported memory module capacities4GB
Supported memory module capacities1GB
Supported memory module capacities12GB
Supported memory typesDDR4-SDRAM
Unbuffered memoryYes
Network
Ethernet interface typeGigabit Ethernet
Ethernet LANYes
LAN controllerRealtek RTL8111H
Wi-FiNo
Packaging content
Batteries includedYes
Bundled softwareNorton® Internet Security (OEM version) LAN bandwidth management software
Cables includedSATA
Packaging data
Package depth235 mm
Package height52 mm
Package weight717 g
Package width265 mm
Processor
Compatible processor seriesIntel® Core™ i7
Compatible processor seriesIntel® Core™ i9
Compatible processor seriesIntel® Celeron®
Compatible processor seriesIntel® Pentium® Gold
Compatible processor seriesIntel® Core™ i3
Maximum number of SMP processors1
Processor manufacturerIntel
Processor socketLGA 1700
Rear panel I/O ports
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.1
Headphone outputs1
Line-inYes
Microphone inYes
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB connector typeUSB Type-A
Safety warning
WarningsBefore starting any maintenance or installation, disconnect the product from the power supply.
WarningsAvoid direct contact with electronics to prevent electrostatic damage.
WarningsDo not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
Storage controllers
Number of HDDs supported2
Number of storage drives supported3
Supported storage drive interfacesM.2, SATA III
Supported storage drive typesHDD & SSD
Technical details
Warranty period3 year(s)
Weight & dimensions
Depth185 mm
Height35 mm
Width226 mm
