Дома / ///Seasonic G12 GM power supply unit 650 W 20+4 pin ATX ATX Black
Новый Seasonic G12 GM power supply unit 650 W 20+4 pin ATX ATX Black

Seasonic G12 GM power supply unit 650 W 20+4 pin ATX ATX Black

Seasonic

NESE-186

Новый продукт

92 Элементы

Shipping 2025-11-25 days

99,00 € включая налог.

Certificates
Compliance certificatesRoHS
Compliance certificatesCE
Design
Cooling typeActive
Fan diameter12 cm
Number of fans1 fan(s)
On/off switchYes
Product colourBlack
Logistics data
Warranty period5 year(s)
Operational conditions
Operating temperature (T-T)0 - 50 °C
Packaging content
Cable tie(s) includedYes
Cables includedAC, PCIe, Peripheral (Molex), SATA
Packaging data
Package typeBox
Performance
80 PLUS certification80 PLUS Gold
Bearing technologySleeve
Mean time between failures (MTBF)100000 h
Power supply unit (PSU) form factorATX
PurposePC
Ports & interfaces
Cabling typeSemi-Modular
Motherboard power cable length55 cm
Motherboard power connector20+4 pin ATX
Number of SATA power connectors6
PCI Express power cable length70 cm
PCI Express power connectors (6+2 pin)2
Peripheral (Molex) power cable length690 mm
Peripheral (Molex) power connectors (4-pin)3
Power
AC input frequency50/60 Hz
AC input voltage100 - 240 V
Combined power (-12V)3.6 W
Combined power (+12V)648 W
Combined power (+3.3V)100 W
Combined power (+5V)100 W
Combined power (+5Vsb)12.5 W
Input current10 A
Max output current (-12V)3.6 A
Max output current (+12V)45 A
Max output current (+3.3V)20 A
Max output current (+5V)20 A
Max output current (+5Vsb)2.5 A
Power protection featuresShort circuit
Power protection featuresOver voltage
Power protection featuresOver current
Total power650 W
Weight & dimensions
Depth140 mm
Height86 mm
Width150 mm
