DeepCool PL750D WH power supply unit 750 W 20+4 pin ATX ATX White

DEEPCOOL

R-PL750D-FC0W-EU-V2

Новый продукт

76 Элементы

Shipping 2025-11-17 days

79,00 € включая налог.

Design
Cooling typeActive
Fan diameter12 cm
Fan locationTop
Number of fans1 fan(s)
On/off switchYes
Product colourWhite
Operational conditions
Operating temperature (T-T)0 - 40 °C
Packaging data
Package typeBox
Performance
80 PLUS certification80 PLUS Bronze
ATX version3.1
Bearing technologyHYB
CertificationCE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH
Mean time between failures (MTBF)100000 h
Power supply unit (PSU) form factorATX
PurposePC
Ports & interfaces
ATX power connector (20+4 pin)Yes
Cabling typeNon-Modular
CPU power connector (4+4 pin)Yes
Motherboard power connector20+4 pin ATX
Number of SATA power connectors7
PCI Express power connectors (16-pin)1
PCI Express power connectors (6+2 pin)3
Peripheral (Molex) power connectors (4-pin)2
Power
AC input frequency50/60 Hz
AC input voltage100 - 240 V
Combined power (-12V)3.6 W
Combined power (+12V)750 W
Combined power (+3.3V)100 W
Combined power (+5V)100 W
Combined power (+5Vsb)15 W
Efficiency85%
Hold time16 ms
Input current10 - 5 A
Max output current (-12V)0.3 A
Max output current (+12V)62.5 A
Max output current (+3.3V)20 A
Max output current (+5V)20 A
Max output current (+5Vsb)3 A
Power Factor Correction (PFC) typeActive
Power Good signal delay range100 - 150 ms
Power protection featuresUnder voltage
Power protection featuresOver current
Power protection featuresOverheating
Power protection featuresSurge protection
Power protection featuresOver power
Power protection featuresNo load operation
Power protection featuresSurge & inrush protection (SIP)
Power protection featuresOver voltage
Total power750 W
Technical details
Compliance certificatesWEEE
Compliance certificatesRoHS
Sustainability certificatesTriman
Sustainability certificatesErP
Sustainability complianceYes
Weight & dimensions
Depth140 mm
Height86 mm
Width150 mm
