Дома / ///DeepCool PL650D power supply unit 650 W 20+4 pin ATX ATX White
Новый DeepCool PL650D power supply unit 650 W 20+4 pin ATX ATX White

DeepCool PL650D power supply unit 650 W 20+4 pin ATX ATX White

DEEPCOOL

R-PL650D-FC0W-JDEU-V2

Новый продукт

102 Элементы

Shipping 2025-11-14 days

69,00 € включая налог.

Certificates
CertificationCE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH
Compliance certificatesRoHS
Compliance certificatesWEEE
Design
Cooling typeActive
Fan diameter12 cm
Fan locationTop
Number of fans1 fan(s)
On/off switchYes
Product colourWhite
Operational conditions
Operating temperature (T-T)0 - 40 °C
Packaging data
Package typeBox
Performance
80 PLUS certification80 PLUS Bronze
ATX version3.0
Bearing technologyHYB
Mean time between failures (MTBF)100000 h
Power supply unit (PSU) form factorATX
PurposePC
Ports & interfaces
ATX power connector (20+4 pin)Yes
Cabling typeNon-Modular
CPU power connector (4+4 pin)Yes
Motherboard power cable length55 cm
Motherboard power connector20+4 pin ATX
Number of SATA power connectors6
PCI Express power connectors (16-pin)1
PCI Express power connectors (6+2 pin)3
Peripheral (Molex) power connectors (4-pin)2
SATA power cable length450 mm
SATA power cable length550
SATA power cable length650
Power
AC input frequency50/60 Hz
AC input voltage100 - 240 V
Combined power (-12V)3.6 W
Combined power (+12V)648 W
Combined power (+3.3V)100 W
Combined power (+5V)100 W
Combined power (+5Vsb)15 W
Efficiency85%
Hold time16 ms
Input current9 - 4.5 A
Max output current (-12V)0.3 A
Max output current (+12V)54 A
Max output current (+3.3V)20 A
Max output current (+5V)20 A
Max output current (+5Vsb)3 A
Power Factor Correction (PFC) typeActive
Power Good signal delay range100 - 150 ms
Power protection featuresOver voltage
Power protection featuresUnder voltage
Power protection featuresOver current
Power protection featuresOver power
Power protection featuresNo load operation
Power protection featuresOverheating
Power protection featuresSurge protection
Power protection featuresSurge & inrush protection (SIP)
Total power650 W
Technical details
Sustainability certificatesTriman
Sustainability certificatesErP
Sustainability complianceYes
Weight & dimensions
Depth140 mm
Height86 mm
Width150 mm
