| Design | |
| Antenna | Yes |
| Antenna design | External |
| Component for | PC |
| Internal | Yes |
| Operating modes | Infrastructure mode |
| Product colour | Red |
| Product colour | Black |
| Transmitting power (FCC) | 5 GHz: 20dBm, 2.4 GHz: 20dBm, 6 GHz: 12dBm |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Network | |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Maximum data transfer rate | 5400 Mbit/s |
| Networking standards | IEEE 802.11ax |
| Networking standards | IEEE 802.11ac |
| Networking standards | IEEE 802.11b |
| Networking standards | IEEE 802.11a |
| Networking standards | IEEE 802.11g |
| Networking standards | IEEE 802.11n |
| Security algorithms | WPA |
| Security algorithms | WPA2-PSK |
| Security algorithms | WEP |
| Security algorithms | WPA-PSK |
| Security algorithms | WPA3 |
| Security algorithms | WPA2 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi standards | 802.11g |
| Wi-Fi standards | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | 802.11b |
| Wi-Fi standards | 802.11a |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rates supported | 11 |
| WLAN data transfer rates supported | 1732 |
| WLAN data transfer rates supported | 2402 Mbit/s |
| WLAN data transfer rates supported | 54 |
| WLAN data transfer rates supported | 300 |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Packaging content | |
| Bluetooth header cable | Yes |
| Mounting brackets included | Yes |
| Quick installation guide | Yes |
| Resource CD | Yes |
| Packaging data | |
| Package depth | 216.5 mm |
| Package height | 48.5 mm |
| Package weight | 480 g |
| Package width | 271.5 mm |
| Ports & interfaces | |
| Connectivity technology | Wireless |
| Host interface | PCI Express |
| Interface | WLAN / Bluetooth |
| Sustainability | |
| Sustainability compliance | Yes |
| System requirements | |
| Windows operating systems supported | Windows 10 Pro x64 |
| Windows operating systems supported | Windows 10 Education x64 |
| Windows operating systems supported | Windows 11 Enterprise x64 |
| Windows operating systems supported | Windows 11 x64 |
| Windows operating systems supported | Windows 10 Enterprise x64 |
| Windows operating systems supported | Windows 10 x64 |
| Windows operating systems supported | Windows 10 Home x64 |
| Technical details | |
| Compliance certificates | RoHS |
| Compliance certificates | CE |
| Compliance certificates | Federal Communications Commission (FCC) |
| Weight & dimensions | |
| Depth | 120.8 mm |
| Height | 21.5 mm |
| Width | 95.2 mm |
