| Certificates | |
| Certification | CE, FCC |
| Design | |
| Enclosure material | Metal |
| LED indicators | Yes |
| Number of fans | 3 fan(s) |
| Product colour | Black |
| Rack capacity | 1U |
| Logistics data | |
| Country of origin | Germany |
| Customs product code (TARIC) | 85176200 |
| Harmonized System (HS) code | 85176990 |
| Management features | |
| Multicast support | Yes |
| Performance management | SLA-Monitor (ICMP) |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| Syslog | Yes |
| Network | |
| Networking standards | IEEE 802.1x |
| Networking standards | IEEE 802.11u |
| Networking standards | IEEE 802.11r |
| Wi-Fi | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 5 - 40 °C |
| Packaging data | |
| Package depth | 200 mm |
| Package height | 335 mm |
| Package weight | 4.88 kg |
| Package width | 550 mm |
| Performance | |
| Control display unit | No |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 5 |
| USB 2.0 ports quantity | 1 |
| Power | |
| Input frequency | 50/60 Hz |
| Input voltage | 110 - 230 V |
| Power consumption (max) | 30 W |
| Protocols | |
| DHCP client | Yes |
| DHCP server | Yes |
| DMZ support | Yes |
| Management protocols | CAPWAP |
| Routing protocols | OSPFv2 |
| Routing protocols | BGP4 |
| Routing protocols | RIP-2 |
| Routing protocols | LISP |
| Supported protocols | Ethernet over GRE-Tunnel (EoGRE), L2TPv3, ARP-Lookup, LLDP, DHCP option 82, IPv6-Router-Advertisement-Snooping, DHCPv6-Snooping, LDRA (Lightweight DHCPv6 Relay Agent), Spanning Tree, Rapid Spanning Tree, ARP, Proxy ARP, BOOTP, DHCP, LACP |
| Security | |
| Access Control List (ACL) | Yes |
| Authentication method | PAP, CHAP, MS-CHAP, MS-CHAPv2 |
| Firewall security | Yes |
| MAC address filtering | Yes |
| Number of VLANs | 4096 |
| Password protection | Yes |
| Security algorithms | 128-bit WEP |
| Security algorithms | 64-bit WEP |
| Security algorithms | WPA2 |
| Security algorithms | WPA2-Enterprise |
| Security algorithms | WPA |
| Security algorithms | 152-bit WEP |
| VLAN support | Yes |
| Weight & dimensions | |
| Depth | 207 mm |
| Height | 45 mm |
| Weight | 3.5 kg |
| Width | 435 mm |
