Home / ///Zyxel XGS2220-30HP Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
New Zyxel XGS2220-30HP Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Zyxel XGS2220-30HP Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

ZyXEL

XGS2220-30HP-EU0101F

New product

2 Items

Shipping 0001-01-05 days

Warning: Last items in stock!

589,00 € tax incl.

Certificates
Compliance certificatesRoHS
Compliance certificatesCE
Compliance certificatesLow Voltage Directive (LVD)
Compliance certificatesFederal Communications Commission (FCC)
Data transmission
Forwarding rate125 Mpps
Jumbo frames supportYes
MAC address table32000 entries
Packet buffer memory2 MB
Static routeYes
Switching capacity168 Gbit/s
Design
LED indicatorsYes
Product colourBlack
Rack mountingYes
Management features
ARP inspectionYes
Cloud-managedYes
Quality of Service (QoS) supportYes
Switch layerL3
Switch typeManaged
Web-based managementYes
Multicast features
Multicast Listener Discovery (MLD) snoopingMLD v1/v2
Multicast supportYes
Network
10G supportYes
Networking standardsIEEE 802.3ab
Networking standardsIEEE 802.1Q
Networking standardsIEEE 802.3x
Networking standardsIEEE 802.1p
Networking standardsIEEE 802.1ab
Networking standardsIEEE 802.1x
Networking standardsIEEE 802.3bt
Networking standardsIEEE 802.3at
Networking standardsIEEE 802.3af
Networking standardsIEEE 802.3az
Networking standardsIEEE 802.3an
Networking standardsIEEE 802.3z
Networking standardsIEEE 802.3ae
Routing entries64
Operational conditions
Heat dissipation1626.57 BTU/h
Operating relative humidity (H-H)10 - 95%
Operating temperature (T-T)-20 - 50 °C
Storage relative humidity (H-H)10 - 90%
Storage temperature (T-T)-40 - 70 °C
Packaging data
Package depth503 mm
Package height95 mm
Package weight5.77 kg
Package width580 mm
Performance
Flash memory64 MB
Internal memory1024 MB
Mean time between failures (MTBF)268.305 h
Ports & interfaces
10G Ethernet (copper) ports quantity2
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity4
Power
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Power consumption (max)477 W
Power sourceAC
Power supply includedYes
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity26
Total Power over Ethernet (PoE) budget400 W
Protocols
GARP VLAN Registration Protocol (GVRP)Yes
Security
Authentication typeIEEE 802.1x, RADIUS, TACACS+
BPDU filtering/protectionYes
DHCP featuresDHCP server
DHCP featuresDHCP relay
IGMP proxyYes
IGMP snoopingYes
Security algorithmsSNMPv2
Security algorithmsSNMPv3
Security algorithmsSNMP
Weight & dimensions
Depth330 mm
Height44 mm
Weight4.35 kg
Width441 mm
