Home / ///LANCOM XS-5116QF Managed L2/L3 10G Ethernet (100/1000/10000) 1U Black
New LANCOM XS-5116QF Managed L2/L3 10G Ethernet (100/1000/10000) 1U Black

LANCOM XS-5116QF Managed L2/L3 10G Ethernet (100/1000/10000) 1U Black

No name

2205059

New product

25 Items

Shipping 2025-11-24 days

6 459,00 € tax incl.

Data transmission
Jumbo frames12000
Jumbo frames supportYes
MAC address table32000 entries
Packet buffer memory4 MB
Throughput440000 Mpps
Design
Form factor1U
LED indicatorsYes
Number of fans2 fan(s)
Product colourBlack
Rack mountingYes
Logistics data
Country of originTaiwan
Customs product code (TARIC)85176200
Harmonized System (HS) code85176990
Management features
Configuring Location Settings (CLI)Yes
MIB supportY
Quality of Service (QoS) supportYes
Switch layerL2/L3
Switch typeManaged
Multicast features
Multicast supportYes
Network
10G supportYes
Broadcast storm controlYes
Ethernet LAN data rates1000,2500,5000,10000 Mbit/s
Flow control supportYes
IP routingYes
IPv4 routes16000
IPv6 routes16000
Link aggregationYes
Networking standardsIEEE 802.1x
Networking standardsIEEE 802.3ad
Networking standardsIEEE 802.1s
Networking standardsIEEE 802.3
Networking standardsIEEE 802.3ab
Networking standardsIEEE 802.1ab
Networking standardsIEEE 802.3x
Networking standardsIEEE 802.3ak
Networking standardsIEEE 802.1D
Networking standardsIEEE 802.3ae
Networking standardsIEEE 802.1w
Number of VLANs4093
Policy-based routingYes
Port mirroringYes
Spanning tree protocolYes
Virtual LAN featuresVoice VLAN
Virtual LAN featuresPrivate VLAN
VLAN supportYes
Operational conditions
Heat dissipation157 BTU/h
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Packaging content
Cables includedSerial
Cables includedMicro-USB
Cables includedAC
ManualYes
Packaging data
Package depth534 mm
Package height100 mm
Package weight6 kg
Package width470 mm
Performance
Firmware upgradeableYes
Noise level40 dB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity2
Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
Console portRJ-45/micro-USB
QSFP+ module slots quantity2
SFP+ module slots quantity12
Power
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Number of power supply units2
Power consumption (max)46 W
Power sourceAC
Protocols
GARP VLAN Registration Protocol (GVRP)Yes
Management protocolsSNMP
Routing protocolsOSPFv2
Routing protocolsOSPFv3
Security
Access Control List (ACL)Yes
Authentication typeRADIUS
DHCP featuresDHCP server
DHCP featuresDHCP client
DHCP featuresDHCP relay
IGMP snoopingYes
Security algorithmsSNMP
Security algorithmsSNMPv2
Security algorithmsSNMPv3
SSH/SSL supportYes
Weight & dimensions
Depth375 mm
Height44 mm
Weight4.9 kg
Width442 mm
