New TP-Link 5-Port 10/100/1000Mbps Desktop Network Switch

TP-Link 5-Port 10/100/1000Mbps Desktop Network Switch

TP-LINK

TL-LS105G

New product

175 Items

Shipping 2025-11-14 days

19,00 € tax incl.

Certificates
CertificationCE, FCC, RoHS
Data transmission
Forwarding rate7.4 Mpps
Jumbo frames16000
Jumbo frames supportYes
MAC address table2000 entries
Packet buffer memory1 MB
Switching capacity10 Gbit/s
Design
Housing materialMetal
LED indicatorsPower
LED indicatorsActivity
LED indicatorsLAN
Product colourBlue
Rack mountingNo
Wall mountableYes
Logistics data
Harmonized System (HS) code85176990
Management features
Quality of Service (QoS) supportYes
Switch typeUnmanaged
Network
10G supportNo
Auto MDI/MDI-XYes
Auto-negotiationYes
Networking standardsIEEE 802.3ab
Networking standardsIEEE 802.1p
Networking standardsIEEE 802.3x
Networking standardsIEEE 802.3u
Networking standardsIEEE 802.3i
Operational conditions
Heat dissipation9.466 BTU/h
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90%
Storage temperature (T-T)-40 - 70 °C
Packaging content
Quick start guideYes
Packaging data
Package depth128 mm
Package height92 mm
Package weight290 g
Package width125 mm
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity5
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity5
Power connectorDC-in jack
Power
Input current0.6 A
Input voltage5 V
Power consumption (max)2.776 W
Power sourceDC
Power supply includedYes
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Safety warning
WarningsEnsure the unit is adequately ventilated during operation.
WarningsThe product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations.
WarningsDo not open the case or try to repair it yourself.
Weight & dimensions
Depth98 mm
Height25 mm
Width99.8 mm
