Home / ///HPE Aruba Networking AP-565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP
New HPE Aruba Networking AP-565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP

HPE Aruba Networking AP-565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP

No name

R4W43A

New product

7 Items

Shipping 2025-11-20 days

819,00 € tax incl.

Antenna
Antenna direction typeOmni-directional
Antenna featuresIntegrated antenna
Antenna gain level (max)5.4 dBi
Antenna typeInternal
Certificates
CertificationNone
Compliance certificatesLow Voltage Directive (LVD)
Design
PlacementPole, Wall
Product colourWhite
Features
2.4 GHzYes
5 GHzYes
BluetoothYes
Bluetooth version5.0
Ethernet LAN data rates100
Ethernet LAN data rates10
Ethernet LAN data rates1000 Mbit/s
Maximum data transfer rate1774 Mbit/s
Maximum data transfer rate (2.4 GHz)574 Mbit/s
Maximum data transfer rate (5 GHz)1200 Mbit/s
MDI / DMI-X automatic switchoverYes
MIMOYes
MIMO typeMulti User MIMO
Modulation64-QAM
ModulationCCK
Modulation1024-QAM
Modulation256-QAM
Modulation16-QAM
ModulationBPSK
ModulationQPSK
Networking standardsIEEE 802.15.4
Spread spectrum methodDSSS
Spread spectrum methodOFDM
Spread spectrum methodOFDMA
Logistics data
Harmonized System (HS) code85176990
Operational conditions
Operating altitude0 - 3000 m
Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)-40 - 55 °C
Storage temperature (T-T)-40 - 70 °C
Ports & interfaces
Ethernet LAN (RJ-45) ports1
USB connector typeUSB Type-C
Power
Power consumption (max)15.6 W
Power over Ethernet (PoE)Yes
Security
Security algorithmsWPA3
Security algorithmsWPA2
Weight & dimensions
Depth165 mm
Height110 mm
Weight1.03 kg
Width165 mm
