Home / ///Seasonic Vertex PX-1000 power supply unit 1000 W 24-pin ATX ATX Black
New Seasonic Vertex PX-1000 power supply unit 1000 W 24-pin ATX ATX Black

Seasonic Vertex PX-1000 power supply unit 1000 W 24-pin ATX ATX Black

Seasonic

100138661

New product

4 Items

Shipping 2025-11-24 days

309,00 € tax incl.

Certificates
Compliance certificatesREACH
Compliance certificatesWEEE
Compliance certificatesRoHS
Design
Cooling typeActive
Fan diameter13.5 cm
Number of fans1 fan(s)
Product colourBlack
Operational conditions
Operating temperature (T-T)0 - 50 °C
Packaging content
Cables includedCPU, PCIe, Peripheral (Molex), SATA
Packaging data
Package typeBox
Performance
80 PLUS certification80 PLUS Platinum
ATX version3.0
Bearing technologyFDB
Mean time between failures (MTBF)150000 h
Power supply unit (PSU) form factorATX
PurposePC
Ports & interfaces
ATX power connector (20+4 pin)Yes
Cabling typeFully-Modular
CPU power cable length65 cm
EPS power connector (8-pin)Yes
Motherboard power cable length61 cm
Motherboard power connector24-pin ATX
PCI Express power cable length75 cm
PCI Express power connectors (16-pin)1
Peripheral (Molex) power cable length690 mm
Peripheral (Molex) power cable length470
Peripheral (Molex) power connectors (4-pin)3
SATA power cable length760 mm
SATA power cable length700
SATA power cable length950 mm
SATA power cable length550
SATA power cable length470
SATA power cable length860 mm
SATA power cable length570
Power
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Combined power (-12V)3.6 W
Combined power (+12V)996 W
Combined power (+3.3V)125 W
Combined power (+5V)125 W
Combined power (+5Vsb)15 W
Input current13 - 6.5 A
Max output current (-12V)0.3 A
Max output current (+12V)83 A
Max output current (+3.3V)25 A
Max output current (+5V)25 A
Max output current (+5Vsb)3 A
Power protection featuresOver power
Power protection featuresOverheating
Power protection featuresOver current
Power protection featuresShort circuit
Power protection featuresOver voltage
Power protection featuresUnder power
Total power1000 W
Safety warning
Hazard pictogram(s)GHS07: Harmful
Hazard pictogram(s)GHS02: Flammable
Hazard pictogram(s)GHS09: Environmental hazard
WarningsDo not open the case - risk of electric shock.
WarningsAvoid contact of the product with water or other liquids.
WarningsThe product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
Technical details
Sustainability certificatesENERGY STAR
Weight & dimensions
Depth160 mm
Height86 mm
Width150 mm
