Home / ///be quiet! Dark Power Pro 13 | 1300W power supply unit 20+4 pin ATX ATX Black
New be quiet! Dark Power Pro 13 | 1300W power supply unit 20+4 pin ATX ATX Black

be quiet! Dark Power Pro 13 | 1300W power supply unit 20+4 pin ATX ATX Black

BE QUIET!

BN331

New product

5 Items

Shipping 0001-01-05 days

449,00 € tax incl.

Design
Cooling typeActive
Fan diameter13.5 cm
Number of fans1 fan(s)
Product colourBlack
Logistics data
Products per shipping (inner) case2 pc(s)
Shipping (inner) case height28.3 cm
Shipping (inner) case length44 cm
Shipping (inner) case net weight14.4 kg
Shipping (inner) case width32.5 cm
Packaging content
Cable tie(s) includedYes
Cables includedCPU, PCIe, Peripheral (Molex), SATA
Packaging data
Package depth417 mm
Package height152 mm
Package weight6.8 kg
Package width253 mm
Performance
80 PLUS certification80 PLUS Titanium
ATX version3.0
Bearing technologyFDB
EPS version2.92
Mean time between failures (MTBF)100000 h
Noise level23.2 dB
Power supply unit (PSU) form factorATX
PurposePC
Ports & interfaces
ATX power connector (20+4 pin)Yes
Cabling typeFully-Modular
CPU power cable length70 cm
EPS power connector (4+4 pin)Yes
EPS power connector (8-pin)Yes
Motherboard power cable length60 cm
Motherboard power connector20+4 pin ATX
Number of PATA power connectors5
Number of SATA power connectors16
PCI Express connectorYes
PCI Express power cable length60 cm
PCI Express power connectors (6+2 pin)6
Peripheral (Molex) power cable length750 mm
Peripheral (Molex) power cable length600 mm
Peripheral (Molex) power cable length900 mm
Peripheral (Molex) power cable length1050 mm
SATA power cable length1050
SATA power cable length900 mm
SATA power cable length750
SATA power cable length950 mm
SATA power cable length800
SATA power cable length500 mm
SATA power cable length600 mm
Power
AC input frequency50 - 60 Hz
AC input voltage115 - 240 V
Combined power (-12V)6 W
Combined power (+12V)1300 W
Combined power (+3.3V)150 W
Combined power (+5V)150 W
Combined power (+5Vsb)17.5 W
Efficiency94.5%
Hold time18 ms
Input current15 - 9 A
Max output current (-12V)0.5 A
Max output current (+12V1)35 A
Max output current (+12V2)35 A
Max output current (+12V3)40 A
Max output current (+12V4)40 A
Max output current (+3.3V)25 A
Max output current (+5V)25 A
Max output current (+5Vsb)3.5 A
Peak power1400 W
Power factor0.99
Power protection featuresUnder voltage
Power protection featuresOver current
Power protection featuresOverheating
Power protection featuresShort circuit
Power protection featuresOver voltage
Power protection featuresOver power
Total power1300 W
Safety warning
WarningsAvoid contact of the product with water or other liquids.
WarningsDo not open the case - risk of electric shock.
WarningsThe product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
Technical details
Compliance certificatesCE
Compliance certificatesFederal Communications Commission (FCC)
Compliance certificatesUKCA
Compliance certificatesCCC
Sustainability complianceYes
Warranty period10 year(s)
Weight & dimensions
Depth200 mm
Height86 mm
Weight2.41 kg
Width150 mm
