Home / ///ASUS PRIME B850-PLUS WIFI AMD B850 Socket AM5 ATX
New ASUS PRIME B850-PLUS WIFI AMD B850 Socket AM5 ATX

ASUS PRIME B850-PLUS WIFI AMD B850 Socket AM5 ATX

ASUS

522732

New product

9 Items

Shipping 2025-11-20 days

259,00 € tax incl.

BIOS
BIOS memory size256 Mbit
BIOS typeUEFI AMI
Expansion slots
Number of M.2 (M) slots3
PCI Express x16 (Gen 3.x) slots2
PCI Express x16 (Gen 4.x) slots1
Features
Audio output channels7.1 channels
Compatible operating systemsWindows 11, Windows 10 64-bit
Component forPC
Motherboard chipsetAMD B850
Motherboard chipset familyAMD
Motherboard form factorATX
Product colourMulticolour
Windows operating systems supportedWindows 11
Windows operating systems supportedWindows 10 x64
Graphics
On-board graphics cardNo
Parallel processing technology supportNot supported
Internal I/O
12V power connectorYes
ATX Power connector (24-pin)Yes
Chassis intrusion connectorYes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Number of chassis fan connectors4
Number of COM connectors1
Number of CPU fan connectors1
Number of SATA III connectors4
S/PDIF out connectorYes
Thunderbolt headers1
TPM connectorYes
USB 2.0 connectors3
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Memory
ECC сompatibilityECC & Non-ECC
Maximum internal memory256 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory clock speed (max)8000 MHz
Supported memory typesDDR5-SDRAM
Unbuffered memoryYes
Network
BluetoothYes
Bluetooth version5.3
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Wi-FiYes
Other features
Weight1.05 kg
Packaging data
Package depth68 mm
Package height273 mm
Package weight1.26 kg
Package width353 mm
Processor
Compatible processor seriesAMD Ryzen 7000 Series
Compatible processor seriesAMD Ryzen 8000 Series
Compatible processor seriesAMD Ryzen 9000 Series
Processor manufacturerAMD
Processor socketSocket AM5
Rear panel I/O ports
DisplayPorts quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
Microphone inYes
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Storage controllers
Number of HDDs supported4
Number of storage drives supported7
RAID levels10
RAID levels5
RAID levels1
RAID supportYes
Supported storage drive interfacesM.2, SATA III
Supported storage drive typesHDD & SSD
Weight & dimensions
Depth244 mm
Height48 mm
Width305 mm
