| Design | |
| Certification | FCC, CE |
| Compliance industry standards | IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| LED indicators | Link |
| Network | |
| Auto MDI/MDI-X | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.3z |
| Networking standards | IEEE 802.3x |
| Networking standards | IEEE 802.1ab |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Other features | |
| Dimensions (WxDxH) | 94.5 x 73 x 27 mm |
| Packaging data | |
| Package depth | 165 mm |
| Package height | 65 mm |
| Package weight | 420 g |
| Package width | 204 mm |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber optic connector | SFP |
| Fiber ports quantity | 1 |
| Power | |
| Power consumption (max) | 3.95 W |
| Weight & dimensions | |
| Depth | 73 mm |
| Height | 27 mm |
| Width | 94.5 mm |
