Home / ///MB ASUS TUF GAMING B650M-E
New MB ASUS TUF GAMING B650M-E

MB ASUS TUF GAMING B650M-E

AMD

90MB1FU0-M0EAY0

New product

13 Items

Shipping 2025-11-20 days

169,00 € tax incl.

BIOS
BIOS typeUEFI AMI
Expansion slots
Number of M.2 (M) slots2
PCI Express x1 (Gen 4.x) slots2
PCI Express x16 (Gen 4.x) slots1
Features
Audio output channels7.1 channels
Motherboard chipsetAMD B650
Motherboard chipset familyAMD
Motherboard form factormicro ATX
Windows operating systems supportedWindows 11
Windows operating systems supportedWindows 10 x64
Graphics
Parallel processing technology supportNot supported
Internal I/O
12V power connectorYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Number of chassis fan connectors2
Number of COM connectors1
Number of SATA III connectors8
Peripheral (Molex) power connectors (4-pin)1
RGB LED pin headerYes
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Memory
ECC сompatibilityECC & Non-ECC
Maximum internal memory128 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory clock speed (max)6400 MHz
Supported memory clock speeds4800 MHz
Supported memory clock speeds6000
Supported memory clock speeds6400
Supported memory clock speeds5200
Supported memory clock speeds6200
Supported memory clock speeds5800
Supported memory clock speeds5400
Supported memory clock speeds5000
Supported memory clock speeds5600
Supported memory typesDDR5-SDRAM
Unbuffered memoryYes
Network
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
Wi-FiNo
Packaging content
Cables includedSATA
Packaging data
Package depth275 mm
Package height67.4 mm
Package weight1.61 kg
Package width275 mm
Processor
Compatible processor seriesAMD Ryzen 7000 Series
Processor manufacturerAMD
Processor socketSocket AM5
Supported processor socketsSocket AM5
Rear panel I/O ports
DisplayPorts quantity2
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
Headphone outputs1
Line-inYes
Microphone inYes
PS/2 ports quantity1
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Safety warning
WarningsAvoid contact with liquids to prevent electronic damage.
WarningsDispose of in accordance with local regulations for electronic waste.
WarningsDo not disassemble to avoid damage to internal components and loss of warranty.
Storage controllers
Number of HDDs supported4
Number of storage drives supported6
RAID levels1
RAID levels10
RAID supportYes
Supported storage drive interfacesM.2, SATA III
Supported storage drive typesHDD & SSD
Weight & dimensions
Depth244 mm
Width244 mm
