| Data transmission | |
| Jumbo frames | 9216 |
| Jumbo frames support | Yes |
| MAC address table | 2048 entries |
| Switching capacity | 10 Gbit/s |
| Design | |
| DIN rail mounting | Yes |
| Form factor | DIN rail |
| Housing material | Aluminium |
| International Protection (IP) code | IP30 |
| Product colour | Black |
| Rack mounting | No |
| Stackable | No |
| Management features | |
| Switch type | Unmanaged |
| Network | |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| Full duplex | Yes |
| Networking standards | IEEE 802.3u |
| Networking standards | IEEE 802.3x |
| Networking standards | IEEE 802.3 |
| Networking standards | IEEE 802.3ab |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -40 - 75 °C |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports quantity | 5 |
| Power | |
| Input voltage | 7 - 57 V |
| Power consumption (max) | 1.5 W |
| Power consumption (typical) | 1 W |
| Power source | DC |
| Power supply included | No |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Weight & dimensions | |
| Depth | 50 mm |
| Height | 28 mm |
| Weight | 142 g |
| Width | 113 mm |
