| Design | |
| Built-in display | No |
| Device type | Cellular network router |
| Housing material | Plastic |
| Housing material | Aluminium |
| LED indicators | Yes |
| Market positioning | Industrial |
| Mounting | DIN-rail |
| Product colour | Black |
| Reset button | Yes |
| Ethernet LAN features | |
| Auto MDI/MDI-X | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 |
| Ethernet LAN interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3u |
| Networking standards | IEEE 802.3 |
| Mobile network | |
| 2G bands supported | 900,1800 MHz |
| 3G bands supported | 2100 MHz |
| 3G bands supported | 900 |
| 4G bands supported | 2600 MHz |
| 4G bands supported | 850 |
| 4G bands supported | 2100 |
| 4G bands supported | 800 |
| 4G bands supported | 900 |
| 4G bands supported | 1800 |
| 4G standard | LTE |
| Data network | 3G |
| Data network | 4G |
| Data network | 2G |
| Number of SIM cards | 1 |
| Short Message Service (SMS) | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -40 - 75 °C |
| Performance | |
| Antenna connector type | SMA |
| Antenna type | External |
| Antennas quantity | 3 |
| Built-in processor | Yes |
| Processor frequency | 0.58 GHz |
| RAM capacity | 0.128 GB |
| Web-based management | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Output voltage | 9 - 30 V |
| Power source type | DC |
| Safety warning | |
| Warnings | Do not expose the device to extreme temperatures. |
| Warnings | Do not expose the device to water or moisture. |
| Warnings | Do not dismantle the unit yourself, there is a risk of electric shock. |
| Security | |
| DMZ support | Yes |
| Firewall | Yes |
| Network address translation (NAT) | Yes |
| Port forwarding | Yes |
| Security algorithms | WPA2-PSK |
| Security algorithms | SSH |
| Security algorithms | WPA2-Enterprise |
| Security algorithms | WPA-PSK |
| Security algorithms | HTTPS |
| Security algorithms | WEP |
| Security algorithms | SSL/TLS |
| Security algorithms | WPA-EAP |
| Weight & dimensions | |
| Depth | 74 mm |
| Height | 25 mm |
| Weight | 125 g |
| Width | 83 mm |
| Wireless LAN features | |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11g |
| Wi-Fi standards | 802.11b |
