Home / ///ASUS TUF GAMING X870E-PLUS WIFI7 AMD X870E Socket AM5 ATX
New ASUS TUF GAMING X870E-PLUS WIFI7 AMD X870E Socket AM5 ATX

ASUS TUF GAMING X870E-PLUS WIFI7 AMD X870E Socket AM5 ATX

ASUS

90MB1M70-M0EAY0

New product

10 Items

Shipping 2025-11-20 days

399,00 € tax incl.

BIOS
BIOS memory size256 Mbit
BIOS typeUEFI AMI
Expansion slots
1st M.2 highest PCI Express generation5.0
1st M.2 largest key size2280
2nd M.2 highest PCI Express generation5.0
2nd M.2 largest key size22110
3rd M.2 highest PCI Express generation4.0
3rd M.2 largest key size2280
4th M.2 highest PCI Express generation4.0
4th M.2 largest key size2280
Number of M.2 (M) slots4
PCI Express x1 (Gen 3.x) slots1
PCI Express x16 (Gen 4.x) slots1
Features
Audio output channels7.1 channels
Component forPC
Cooling typePassive
Motherboard chipsetAMD X870E
Motherboard chipset familyAMD
Motherboard form factorATX
Power source typeATX
Product colourGrey
Windows operating systems supportedWindows 11
Graphics
On-board graphics cardNo
Parallel processing technology supportNot supported
Internal I/O
12V power connectorYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Front panel connectorYes
Number of chassis fan connectors4
Number of CPU fan connectors1
Number of EPS power connectors (8-pin)2
Number of RGB LED pin headers3
Number of SATA III connectors4
Number of temperature sensor headers1
Number of water pump connectors1
RGB LED pin headerYes
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
Memory
ECC сompatibilityECC & Non-ECC
Maximum internal memory256 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory clock speed (max)8000 MHz
Supported memory typesDDR5-SDRAM
Unbuffered memoryYes
Network
BluetoothYes
Bluetooth version5.4
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-FiYes
Wi-Fi standardsWi-Fi 7 (802.11be)
Other features
Quick installation guideYes
Weight1.56 kg
Packaging content
Antenna includedYes
Cables includedSATA
Screws includedYes
Packaging data
Package depth273 mm
Package height68 mm
Package weight2.08 kg
Package width353 mm
Processor
Compatible processor seriesAMD Ryzen 8000 Series
Compatible processor seriesAMD Ryzen 7000 Series
Compatible processor seriesAMD Ryzen 9000 Series
Processor manufacturerAMD
Processor socketSocket AM5
Supported processor socketsSocket AM5
Rear panel I/O ports
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
Headphone outputs1
Line-inYes
Microphone inYes
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
USB4 Gen 3x2 ports quantity2
WiFi-AP antenna jack2
Storage controllers
Number of HDDs supported4
Number of storage drives supported8
RAID levels1
RAID levels10
RAID levels5
RAID supportYes
Supported storage drive interfacesM.2, PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive typesHDD & SSD
Weight & dimensions
Depth244 mm
Height48 mm
Width305 mm
