New Asrock B650M PG Lightning AMD B650 Socket AM5 micro ATX

Asrock B650M PG Lightning AMD B650 Socket AM5 micro ATX

Asrock

B650MPGLIGHTNING

New product

27 Items

Shipping 2025-11-14 days

119,00 € tax incl.

BIOS
BIOS typeUEFI AMI
Expansion slots
Number of M.2 (M) slots3
PCI Express x16 (Gen 3.x) slots1
PCI Express x16 (Gen 4.x) slots1
Features
Audio chipRealtek ALC897
Audio output channels7.1 channels
CertificationFCC, CE, ErP/EuP
Motherboard chipsetAMD B650
Motherboard chipset familyAMD
Motherboard form factormicro ATX
Product colourBlack
Windows operating systems supportedWindows 11 x64
Windows operating systems supportedWindows 10 x64
Graphics
HDCPYes
Maximum resolution3840 x 2160 pixels
Parallel processing technology supportCrossFire
Internal I/O
12V power connectorYes
ATX Power connector (24-pin)Yes
Chassis intrusion connectorYes
CPU fan connectorYes
EPS power connector (8-pin)Yes
Front panel audio connectorYes
Number of chassis fan connectors3
Number of SATA III connectors4
RGB LED pin headerYes
Thunderbolt headers1
TPM connectorYes
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors3
Memory
ECC сompatibilityECC & Non-ECC
Maximum internal memory192 GB
Memory slots typeDIMM
Number of memory slots4
Supported memory clock speed (max)7200 MHz
Supported memory clock speeds4800
Supported memory clock speeds4400
Supported memory clock speeds6200
Supported memory clock speeds6600
Supported memory clock speeds5200
Supported memory clock speeds6800
Supported memory clock speeds6000
Supported memory clock speeds7000
Supported memory clock speeds6400
Supported memory clock speeds5600
Supported memory clock speeds7200 MHz
Supported memory typesDDR5-SDRAM
Unbuffered memoryYes
Network
Ethernet interface type2.5 Gigabit Ethernet
Ethernet LANYes
LAN controllerDragon RTL8125BG
Wi-FiNo
Packaging content
Cables includedSATA
Screws includedYes
Processor
Compatible processor seriesAMD Ryzen 7000 Series
Processor manufacturerAMD
Processor socketSocket AM5
Supported processor socketsSocket AM5
Rear panel I/O ports
DisplayPort version1.4
DisplayPorts quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.1
Headphone outputs3
Microphone inYes
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB connector typeUSB Type-A
USB connector typeUSB Type-C
Safety warning
WarningsDispose of in accordance with local regulations for electronic waste.
WarningsDo not disassemble to avoid damage to internal components and loss of warranty.
WarningsAvoid contact with liquids to prevent electronic damage.
Storage controllers
Number of storage drives supported7
RAID levels1
RAID levels10
RAID supportYes
Supported storage drive interfacesM.2, PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive typesHDD & SSD
Weight & dimensions
Depth244 mm
Width244 mm
