| Design | |
| Housing material | Aluminium |
| Housing material | Plastic |
| Product colour | Black |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 85% |
| Operating temperature (T-T) | 0 - 55 °C |
| Storage relative humidity (H-H) | 0 - 85% |
| Storage temperature (T-T) | -10 - 70 °C |
| Packaging content | |
| Manual | Yes |
| Packaging data | |
| Package depth | 203 mm |
| Package height | 50 mm |
| Package type | Box |
| Package weight | 1.08 kg |
| Package width | 250 mm |
| Performance | |
| Data transfer rate (max) | 5 Gbit/s |
| HD type | 4K Ultra HD |
| HDCP | Yes |
| Maximum resolution | 3840 x 2160 pixels |
| Video bandwidth | 60 Hz |
| Ports & interfaces | |
| Audio connections | Yes |
| Console ports | HDMI |
| Console ports | USB A |
| Console ports | USB C |
| Console ports | 3.5mm headphone |
| Console ports | DisplayPort |
| Console ports | RJ–45 |
| Console USB ports quantity | 6 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Headphone outputs | 1 |
| Number of computers controlled | 2 |
| USB 2.0 Type-C ports quantity | 2 |
| Video port type | HDMI |
| Power | |
| Input voltage | 24 V |
| Output current | 5.6 A |
| Sustainability | |
| Compliance certificates | RoHS |
| Compliance certificates | REACH |
| Weight & dimensions | |
| Depth | 79 mm |
| Height | 28 mm |
| Weight | 926 g |
| Width | 185 mm |
