Home / ///Hikvision DS-2TD2617-6/QA security camera Bullet IP security camera Outdoor 2688 x 1520 pixels Wall
New Hikvision DS-2TD2617-6/QA security camera Bullet IP security camera Outdoor 2688 x 1520 pixels Wall

Hikvision DS-2TD2617-6/QA security camera Bullet IP security camera Outdoor 2688 x 1520 pixels Wall

Hikvision

396333

New product

3 Items

Shipping 2025-11-19 days

Warning: Last items in stock!

1 079,00 € tax incl.

Audio
Audio formats supportedMP2L2
Audio formats supportedG.726
Audio formats supportedG.722.1
Audio formats supportedG.711 μ-law
Audio formats supportedG.711 A-law
Audio formats supportedPCM
Audio input channels1.0 channels
Camera
Camera shutter speed1 - 1/100000 s
Field of view (FOV) angle (thermal module)18.7 x 25°
Lens viewing angle, horizontal39.42°
Lens viewing angle, vertical22.14°
Minimum illumination0.0035 lx
Design
Form factorBullet
International Protection (IP) codeIP66
Mounting typeWall
Product colourBlack
Product colourWhite
Image sensor
Effective sensor resolution (thermal module)160 x 120 pixels
Optical sensor size25.4 / 2.7 mm (1 / 2.7")
Sensor typeCMOS
Lens system
Aperture number (thermal module)1.1
Digital zoom4x
Fixed focal length8 mm
Fixed focal length (thermal module)6.2 mm
Infrared spectral band8 - 14 µm
Maximum aperture number1.6
Number of lenses1
Zoom capabilityYes
Management features
Web browserYes
Network
BluetoothNo
Ethernet LANYes
Live viewYes
Number of simultaneous live view channels20 channels
Number of users32 user(s)
Quality of Service (QoS) supportYes
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
User access levelAdministrator, Operator, User
Wi-FiNo
Night vision
Night visionYes
Night vision distance40 m
Operational conditions
Operating relative humidity (H-H)0 - 95%
Operating temperature (T-T)-40 - 65 °C
Other features
Browser supportedInternet Explorer 11, Chrome 57.0 +, Firefox 52.0 +, Chrome 57.0 +, Firefox 52.0
Packaging content
Number of cameras1
Performance
Alarm input/outputYes
Connectivity technologyWired
IFOV (spatial resolution)2.74 mRad
Languages supportDanish
Languages supportDutch
Languages supportCzech
Languages supportSpanish
Languages supportHungarian
Languages supportLithuanian
Languages supportTurkish
Languages supportThai
Languages supportFrench
Languages supportVietnamese
Languages supportItalian
Languages supportTraditional Chinese
Languages supportHRV
Languages supportSlovak
Languages supportGreek
Languages supportEnglish
Languages supportGerman
Languages supportPolish
Languages supportJapanese
Languages supportRussian
Languages supportBulgarian
Languages supportSwedish
Languages supportFinnish
Languages supportEstonian
Languages supportPortuguese
Languages supportSlovenian
Languages supportLAT
Languages supportNorwegian
Languages supportKorean
Languages supportRomanian
Languages supportSER
Number of languages32
Placement supportedOutdoor
Thermal sensitivity (NETD)40 mK
TypeIP security camera
Wide Dynamic Range (WDR)Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Microphone inYes
RS-485 ports1
Power
DC output current0.5 A
DC output voltage12
Power consumption (max)6 W
Power consumption (Power over Ethernet (PoE))6.5 W
Power over Ethernet (PoE)Yes
Power source typeDC, PoE
Security
Alarm input channels2
Alarm output channels2
Automatic Network Replenishment (ANR)Yes
Detection distance182 m
Digest authenticationYes
HTTPS encryptionYes
IP address filteringYes
Temperature measurement accuracy8 °C
Temperature measurement range-20 - 150 °C
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSDHC
Compatible memory cardsMicroSDXC
Compatible memory cardsMicroSD (TransFlash)
Technical details
Output impedance600 Ω
Video
Maximum resolution2688 x 1520 pixels
Noise reduction technology3D noise reduction
Supported graphics resolutions352 x 288
Supported graphics resolutions640 x 480 (VGA)
Supported graphics resolutions704 x 576
Supported graphics resolutions1280 x 720 (HD 720)
Supported graphics resolutions320 x 240
Video compression formatsH.265
Video compression formatsH.264
Video compression formatsM-JPEG
Weight & dimensions
Height115.2 mm
Length358.3 mm
Weight1.76 kg
Width113.5 mm
