| Audio | |
| Audio codecs | PCM; G711A; G711U; G726 |
| Emergency call | Yes |
| Features | |
| Product colour | White |
| Hard drive | |
| HDD interface | SATA |
| Maximum storage capacity | 16 TB |
| Number of SAS ports | 2 |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 93% |
| Operating temperature (T-T) | -10 - 55 °C |
| Performance | |
| Input bandwidth | 180 / 256 Mbit/s |
| Operating system installed | Embedded LINUX |
| Output bandwidth | 180 / 256 Mbit/s |
| Playback modes | Instant playback, general playback, event playback, tag playback, smart playback |
| Recording modes | Motion detection, manual recording, smart recording, alarm |
| SMD Plus | Yes |
| Video input channels | 8 channels |
| Ports & interfaces | |
| Audio RCA outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| HDMI output | Yes |
| HDMI ports quantity | 1 |
| PoE Port | 8*10/100Mbps |
| PoE standard | IEEE 802.3af/at |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) output ports | 1 |
| Power | |
| AC input frequency | 47 - 63 Hz |
| Input voltage | AC 100-240 V |
| Processor | |
| Built-in processor | Yes |
| Safety warning | |
| Warnings | The product must be disposed of properly in accordance with local regulations for the disposal of electronics. |
| Warnings | The appliance should be installed by a qualified professional. |
| Warnings | Do not expose the device to moisture or extreme temperatures. |
| System requirements | |
| Browser supported | Chrome; IE9+; Firefox |
| Mobile operating systems supported | Android |
| Mobile operating systems supported | iOS |
| Video | |
| Maximum resolution (HDMI) | 3840 x 2160 pixels |
| Video codecs | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Weight & dimensions | |
| Depth | 329.3 mm |
| Height | 53 mm |
| Package depth | 147 mm |
| Package height | 425 mm |
| Package weight | 3.66 kg |
| Package width | 451 mm |
| Weight | 2.51 kg |
| Width | 375 mm |
